T3 ANGLE MACHINING
Precision CNC Machining

T3 ANGLE Machining guarantees the quality of our products. New Computer Numerical Control (CNC) technology lines and software are used to manufacture products quickly and accurately with the best quality and low production prices for our customers.

Our staff has over fifteen years of experience in the mechanical manufacturing industry. - " we have a licensed ITAR certificate from the US government"

330618274_116761344682719_1161291146778897905_n

329829288_888760892247032_727570545557608540_n

T3 Angle Machining

“ Your trust is strength for Us ! “

Our Equipment

T3 ANGLE Machining guarantees the quality of our products

Akira Seiki V4AXP Vertical Machining Center

W/Fanuc 0iMF Control: Riggid Tap, USB, RS-232

High Speed Look Ahead, Background Editing, Color LCD

Box Ways Z, Linear Guide Ways X&Y

Options and Accesories if Required (Not Included):

Chip Auger (Screw Type)

28 Position Side-Mount Automatic Tool Changer

12,000 RPM CAT-40 Taper Spindle

1,745 IPM Rapids X&Y, 1,181 IPM Rapids Z

YAMA SEIKI L-1060 / EXTRON high speed CNC machining

ATC:

24-tool swing arm change

Capacity:

Table size: 49.5” x 20”

Spindle nose to table 4.7” – 33.2”

X/Y/Z travel: 40.1” / 24" / 26”

Table Load: 1540 Lbs.

DNM 5700 with FANUC 0i-M control, 30 ATC and 12K spindle

Capacity:

X axis travel: 1,050mm (41.33")

Y axis travel: 570mm (22.44")

Z axis travel: 1300mm x 570mm

Table loading area: (51.18" x 22.44")

1,000 kg (2,205 lbs)

Allowable table load: (4) - 125mm x 18H8

Table T-slot spacing x width: (4) - 4.92" x .71"

GANESH MACHINERY

The VFM-2416, the smallest of the VFM series, features axis travels of 24" x 15.75" x 17.7" (X, Y, Z), with rates of 1,417ipm. The 12,000rpm, 15hp direct-drive 40-taper spindle features rigid tapping and a thermostatically controlled spindle oil cooler. Roller bearing guideways in all three axes provide nearly twice the rigidity of ball bearing ways. A 24-tool, twin-arm, 40-taper automatic tool changer (ATC) is included.

Standard on the machine is 300psi through-the-spindle coolant, with 1,000psi as an option. The Big-Plus dual-contact precision ground spindle offers rigidity, reduced tool runout, and greater cutting capability.
